| Codice | Modello | A mm | B mm | C mm | F mm | G mm | D | L mm | Peso gr. | 3D |
|---|---|---|---|---|---|---|---|---|---|---|
| 6112140 | VP/40 M6x20 | 40 | 21 | 28 | 13 | 15 | M6 | 20 | 33 | 3D |
| 6112145 | VP/40 M6x25 | 40 | 21 | 28 | 13 | 15 | M6 | 25 | 34 | 3D |
| 6112147 | VP/40 M6x30 | 40 | 21 | 28 | 13 | 15 | M6 | 30 | 35 | 3D |
| 6112150 | VP/40 M6x40 | 40 | 21 | 28 | 13 | 15 | M6 | 40 | 37 | 3D |
| 6112155 | VP/40 M8x10 | 40 | 21 | 28 | 13 | 15 | M8 | 10 | 32 | 3D |
| 6112160 | VP/40 M8x15 | 40 | 21 | 28 | 13 | 15 | M8 | 15 | 36 | 3D |
| 6112165 | VP/40 M8x20 | 40 | 21 | 28 | 13 | 15 | M8 | 20 | 38 | 3D |
| 6112170 | VP/40 M8x25 | 40 | 21 | 28 | 13 | 15 | M8 | 25 | 39 | 3D |
| 6112175 | VP/40 M8x30 | 40 | 21 | 28 | 13 | 15 | M8 | 30 | 40 | 3D |
| 6112180 | VP/40 M8x35 | 40 | 21 | 28 | 13 | 15 | M8 | 35 | 42 | 3D |
| 6112185 | VP/40 M8x40 | 40 | 21 | 28 | 13 | 15 | M8 | 40 | 44 | 3D |
| 6112190 | VP/40 M8x50 | 40 | 21 | 28 | 13 | 15 | M8 | 50 | 46 | 3D |
| 6112195 | VP/40 M8x60 | 40 | 21 | 28 | 13 | 15 | M8 | 60 | 51 | 3D |
| 6112205 | VP/40 M8x70 | 40 | 21 | 28 | 13 | 15 | M8 | 70 | 55 | 3D |
| 6112210 | VP/40 M10x20 | 40 | 21 | 28 | 13 | 15 | M10 | 20 | 45 | 3D |
| 6112215 | VP/40 M10x30 | 40 | 21 | 28 | 13 | 15 | M10 | 30 | 50 | 3D |
| 6112220 | VP/40 M10x50 | 40 | 21 | 28 | 13 | 15 | M10 | 50 | 60 | 3D |
| 6112225 | VP/40 M10x70 | 40 | 21 | 28 | 13 | 15 | M10 | 70 | 70 | 3D |
| 6112230 | VP/50 M8x15 | 50 | 25 | 33 | 15 | 18 | M8 | 15 | 51 | 3D |
| 6112235 | VP/50 M8x20 | 50 | 25 | 33 | 15 | 18 | M8 | 20 | 52 | 3D |
| 6112240 | VP/50 M8x25 | 50 | 25 | 33 | 15 | 18 | M8 | 25 | 55 | 3D |
| 6112245 | VP/50 M8x30 | 50 | 25 | 33 | 15 | 18 | M8 | 30 | 56 | 3D |
| 6112250 | VP/50 M8x40 | 50 | 25 | 33 | 15 | 18 | M8 | 40 | 60 | 3D |
| 6112255 | VP/50 M8x45 | 50 | 25 | 33 | 15 | 18 | M8 | 45 | 61 | 3D |
| 6112256 | VP/50 M8x50 | 50 | 25 | 33 | 15 | 18 | M8 | 50 | 61 | 3D |
| 6112260 | VP/50 M8x60 | 50 | 25 | 33 | 15 | 18 | M8 | 60 | 67 | 3D |
| 6112265 | VP/50 M10x15 | 50 | 25 | 33 | 15 | 18 | M10 | 15 | 58 | 3D |
| 6112270 | VP/50 M10x20 | 50 | 25 | 33 | 15 | 18 | M10 | 20 | 61 | 3D |
| 6112275 | VP/50 M10x25 | 50 | 25 | 33 | 15 | 18 | M10 | 25 | 63 | 3D |
| 6112280 | VP/50 M10x30 | 50 | 25 | 33 | 15 | 18 | M10 | 30 | 65 | 3D |
| 6112284 | VP/50 M10x40 | 50 | 25 | 33 | 15 | 18 | M10 | 40 | 70 | 3D |
| 6112285 | VP/50 M10x50 | 50 | 25 | 33 | 15 | 18 | M10 | 50 | 76 | 3D |
| 6112290 | VP/50 M10x60 | 50 | 25 | 33 | 15 | 18 | M10 | 60 | 84 | 3D |
| 6112295 | VP/50 M12x30 | 50 | 25 | 33 | 15 | 18 | M12 | 30 | 86 | 3D |
| 6112300 | VP/50 M12x40 | 50 | 25 | 33 | 15 | 18 | M12 | 40 | 93 | 3D |
| 6112305 | VP/50 M12x60 | 50 | 25 | 33 | 15 | 18 | M12 | 60 | 108 | 3D |
| 6112310 | VP/60 M8x20 | 60 | 28 | 35 | 15 | 20 | M8 | 20 | 75 | 3D |
| 6112315 | VP/60 M8x40 | 60 | 28 | 35 | 15 | 20 | M8 | 40 | 80 | 3D |
| 6112320 | VP/60 M8x60 | 60 | 28 | 35 | 15 | 20 | M8 | 60 | 87 | 3D |
| 6112330 | VP/60 M10x20 | 60 | 28 | 35 | 15 | 20 | M10 | 20 | 82 | 3D |
| 6112335 | VP/60 M10x30 | 60 | 28 | 35 | 15 | 20 | M10 | 30 | 86 | 3D |
| 6112340 | VP/60 M10x35 | 60 | 28 | 35 | 15 | 20 | M10 | 35 | 94 | 3D |
| 6112345 | VP/60 M10x40 | 60 | 28 | 35 | 15 | 20 | M10 | 40 | 96 | 3D |
| 6112350 | VP/60 M10x45 | 60 | 28 | 35 | 15 | 20 | M10 | 45 | 99 | 3D |
| 6112355 | VP/60 M10x60 | 60 | 28 | 35 | 15 | 20 | M10 | 60 | 107 | 3D |
| 6112360 | VP/60 M10x70 | 60 | 28 | 35 | 15 | 20 | M10 | 70 | 110 | 3D |
| 6112365 | VP/60 M12x20 | 60 | 28 | 35 | 15 | 20 | M12 | 20 | 101 | 3D |
| 6112370 | VP/60 M12x30 | 60 | 28 | 35 | 15 | 20 | M12 | 30 | 107 | 3D |
| 6112375 | VP/60 M12x35 | 60 | 28 | 35 | 15 | 20 | M12 | 35 | 107 | 3D |
| 6112380 | VP/60 M12x40 | 60 | 28 | 35 | 15 | 20 | M12 | 40 | 115 | 3D |
| 6112385 | VP/60 M12x50 | 60 | 28 | 35 | 15 | 20 | M12 | 50 | 122 | 3D |
| 6112386 | VP/60 M12x60 | 60 | 28 | 35 | 15 | 20 | M12 | 60 | 127 | 3D |
| 6112390 | VP/60 M12x80 | 60 | 28 | 35 | 15 | 20 | M12 | 80 | 133 | 3D |
| 6112395 | VP/70 M10x30 | 70 | 32 | 42 | 21 | 21 | M10 | 30 | 115 | 3D |
| 6112400 | VP/70 M10x40 | 70 | 32 | 42 | 21 | 21 | M10 | 40 | 116 | 3D |
| 6112405 | VP/70 M12x30 | 70 | 32 | 42 | 21 | 21 | M12 | 30 | 133 | 3D |
| 6112415 | VP/70 M12x40 | 70 | 32 | 42 | 21 | 21 | M12 | 40 | 138 | 3D |
| 6112420 | VP/70 M12x50 | 70 | 32 | 42 | 21 | 21 | M12 | 50 | 145 | 3D |
| 6112425 | VP/70 M12x70 | 70 | 32 | 42 | 21 | 21 | M12 | 70 | 156 | 3D |
| 6112435 | VP/70 M14x40 | 70 | 32 | 42 | 21 | 21 | M14 | 40 | 170 | 3D |
| 6112440 | VP/70 M14x50 | 70 | 32 | 42 | 21 | 21 | M14 | 50 | 181 | 3D |
| 6112445 | VP/90 M12x60 | 90 | 42 | 55 | 26 | 29 | M12 | 60 | 255 | 3D |
| 6112450 | VP/90 M12x70 | 90 | 42 | 55 | 26 | 29 | M12 | 70 | 260 | 3D |
| 6112455 | VP/90 M14x60 | 90 | 42 | 55 | 26 | 29 | M14 | 60 | 283 | 3D |
| 6112460 | VP/90 M14x70 | 90 | 42 | 55 | 26 | 29 | M14 | 70 | 288 | 3D |
| 6112465 | VP/90 M16x60 | 90 | 42 | 55 | 26 | 29 | M16 | 60 | 322 | 3D |
| 6112470 | VP/90 M16x70 | 90 | 42 | 55 | 26 | 29 | M16 | 70 | 328 | 3D |
NOTE:
Beaucoup d’option specialles a votre disposition sur demande.
Demander devis
Vous avez besoin de plus d’informations sur nos produits ?
Remplissez le formulaire, notre représentant vous répondra dans les plus brefs délais.
